Ka Band Power Amplifier
Description:
The ERZ-HPA-3300-3700-38 is a High Power Amplifier providing an output power of 7 W and a gain of 23 dB. The compact size and modularity makes it ideal for a wide range of applications.
Download:
| Frequency Start (GHz) | 33.00
|
|---|---|
| Frequency Stop (GHz) | 37.0
|
| Output Power (dBm) | 38.5
|
| Gain (dB) | 23
|
| Gain flatness (dB) | ±2
|
| Noise Figure (dB) | -
|
| VSWR IN | 1.5:1
|
| VSWR OUT | 1.5:1
|
| Power supply (V) | 24±4
|
| Current (mA) | 3542
|
| Power consumption (W) | 85
|
| Max. Input DC (no damage) (V) | 28
|
| Max. RF input power (dBm) | 30
|
| Temperature (operation) (°C) | -35 to 70
|
| Temperature (storage) (°C) | -55 to +125
|
Applications:
Industrial / Laboratory
Satcom / Telecom
Space / Aerospace / Military
Outline Drawing:
Ordering Information:
