ERZ-HPA-2600-4000-33-A

Ka Band Power Amplifier

Description:

The ERZ-HPA-2600-4000-33-A is a Ka Band High Power Amplifier providing an output power of 33 dBm and gain of 35 dB. The compact size and modularity makes it ideal for a wide range of applications.

Key Features
Frequency Range (GHz):
26.00 to 40.0
Output Power (dBm):
33
Small Signal Gain (dB):
35
Noise Figure (dB):
7
Bias:
12 ±3 VDC
Package Dimensions:
33x59x18.9 mm
Connectors:
2.92 mm Female
Frequency Start (GHz)
26.00
Frequency Stop (GHz)
40.0
Output Power (dBm)
33
Gain (dB)
35
Gain flatness (dB)
±5
Noise Figure (dB)
7
VSWR IN
1.8:1
VSWR OUT
1.8:1
Power supply (V)
12 ±3
Current (mA)
2500
Power consumption (W)
30
Max. Input DC (no damage) (V)
15
Max. RF input power (dBm)
10
Temperature (operation) (°C)
-45 to 85
Temperature (storage) (°C)
-55 to 125
Applications:

Industrial / Laboratory
Satcom / Telecom
Space / Aerospace / Military

Outline Drawing:
Ordering Information:
